Proper Sizing
Determine operating channels, lamp banks, modules, and installed lamp quantities.
Engineering Excel Workbook
UV Disinfection System Design Calculation
Develop a preliminary wastewater UV channel and lamp configuration. Use selected reactor-specific performance inputs to review delivered dose, channel hydraulics, and installed equipment quantities.
Excel WorkbookBuilt-in Design ChecksReview-Ready Output
What This Module Helps You Design
Evaluate Performance
Evaluate delivered UV dose, velocity, flow area, and channel headloss.
Support Design Decisions
Document reactor-specific assumptions and identify items requiring manufacturer validation.
Calculation Coverage
From design basis to configuration and engineering review.
Design Basis
- Average and maximum design flow
- Minimum UV transmittance
- Required treatment dose
- Selected validated-reactor inputs
Channel & Lamp Design
- Operating-channel quantity
- Flow distribution between channels
- Banks, modules, and lamp count
- Channel geometry and sleeve spacing
Performance Review
- Delivered dose estimate
- Channel velocity and flow area
- Hydraulic headloss
- Design-status summary
Workbook Experience
See the Complete Engineering Workflow
Review the actual workbook structure, calculation sequence, design checks, and final outputs before purchase.
Actual UV Disinfection System Dashboard excerpt. Example information illustrates the workbook layout and design basis.
Built-in Design Checks
Review the selected configuration against the adopted design basis.
| Design Check | Workbook Evaluation |
|---|---|
| UV basis | Transmittance and selected reactor inputs reviewed |
| Channel loading | Design flow distributed across operating channels |
| Delivered dose | Estimated dose compared with the adopted target |
| Hydraulic performance | Velocity, flow area, headloss, and spacing evaluated |
| System configuration | Installed quantities and design status summarized |
Criteria and internal calculation logic remain inside the complete workbook.
What's Included
READ ME
Purpose & instructions
Cover
Project information
Calculation
UV and hydraulic workflow
Dashboard
Key outputs
Design Data
Performance inputs
Abbreviations
Symbols & units
AIDIA supports preliminary engineering calculation and review. Final project decisions remain subject to project-specific criteria, professional engineering judgement, and vendor confirmation.
Complete Your UV Disinfection System Design
Move from preliminary sizing and screening to a structured, review-ready engineering workbook.
